ELECTRO GUIDE AND APPLICATION INFORMATION ( RATINGS AT 25° C )
|
Part No. |
Chip |
|
|
Absolute |
Maximum |
LRatings |
|
|
|
| Raw Material |
Emitted Color |
|
|
|
|
VI(V) |
if |
lv(mcd) |
Min. |
Typ. |
Max. |
(Pic) |
Min. |
Typ. |
| L02XHC-SFL |
GaP |
Bright Red |
Water Clear |
700 |
90 |
45 |
15 |
50 |
1.5 |
1.7 |
2.8 |
10 |
|
12.0 |
35 |
| L02XOC-SFL |
GaPSP/GaP |
Orange Red |
Water Clear |
635 |
45 |
100 |
30 |
150 |
1.7 |
2.1 |
2.8 |
10 |
|
37.5 |
35 |
| L02XGC-SFL |
GaP |
Green |
Water Clear |
565 |
30 |
100 |
30 |
150 |
1.7 |
2.8 |
2.8 |
10 |
|
45.0 |
35 |
| L02XSGC-SFL |
GaP |
Bright Green |
Water Clear |
565 |
30 |
100 |
30 |
150 |
1.7 |
2.8 |
2.38 |
10 |
|
65.0 |
35 |
| L02XYC-SFL |
GaPSP/GaP |
Yellow |
Water Clear |
585 |
30 |
100 |
30 |
150 |
1.7 |
2.8 |
2.8 |
10 |
|
30.0 |
35 |
| L02XSC-SFL |
GaAIAs |
Bright Red |
Water Clear |
660 |
20 |
60 |
20 |
150 |
1.6 |
2.1 |
2.1 |
10 |
|
67.5 |
35 |
| L02XUC-SFL |
GaAIAs |
Super Red |
Water Clear |
660 |
20 |
60 |
20 |
150 |
1.6 |
2.1 |
2.1 |
10 |
|
80.0 |
35 |
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
| ABSOLUTE MAXIMUN RATING(Ta=25) |
ELECTRO-OPTICAL CHARACTRISTICS： (Ta=25) |
| Revere Voltage |
5Volt |
| Revere Current(Vr=5V) |
10A |
| Operating Temperature Range |
-40°C to +85°C |
| Storage Temperaure Range |
-40°C to +100°C |
Lead Soldering Temperature
(1.6mm(1/16inch)from body) |
260°C for 5 Seconds |
|
| Para meter Description |
Symbol |
Unit |
| Spectral Line haif-Width |
|
nm |
| Power Dissipation |
Pd |
mW |
| Peak Forward Current (Duty 1/10,@KHz) |
|f(Peak) |
mA |
| Recommended Operation Current |
|f(Pec) |
mA |
| Average Luminous intrnsity (if=10mA) |
|v |
mcd |
|
