1.2" SINGLE DIGIT
 |
Download PDF File
|
 |
JOINSCAN'S LED |
Tester : OPTO Meter S370@20mA |
| PIN FUNCTION | COMMON ANODE | COMMON CATHODE |
|
|
|
|
||||||||||||
A |
C |
E |
B |
D |
F |
|||||||||||||
EMITTING COLOR |
MADEL NO. |
MADEL NO. |
MADEL NO. |
MADEL NO. |
MADEL NO. |
MADEL NO. |
(nm) | VR=5V | IF=20mA | IF=20mA | ||||||||
GAP RED |
A1218H | 0 | A1217H | C1218H | 0 | C1217H | 695 | 100 | 4.4 | 0.6MCD | ||||||||
GaAsp ORANGE RED |
A1218O | A1219C |
A1217O | C1218O | C1219C |
C1217O | 635 | 100 | 4.0 | 4.0MCD | ||||||||
GaP GREEN |
A1218G | A1217G | C1218G | C1217G | 570 | 100 | 4.4 | 4.5MCD | ||||||||||
GaP YELLOW |
A1218Y | 0 | A1217Y | C1218Y | 00 | C1217Y | 600 | 100 | 4.4 | 4.0MCD | ||||||||
GaAIAS RED |
A1218RS | 0 | A1217RS | A1218RS | 0 | C1217RS | 650 | 100 | 3.6 | 8.0MCD | ||||||||
GaAIAS RED |
0 | 00 | 0 | 0 | 00 | 0 | 0 | 0 | 0 | 0 | ||||||||
GaAIAS YELLOW GREEN |
0 | 00 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ||||||||
SIC BLUE |
A1218SF | 0 | A1217SF | C1218SF | 0 | C1217SF | 465±6 | 100 | 7.2 | 2.0MCD | ||||||||
ZNSE WHITE |
A12183 | 0 | A12173 | C12183 | 0 | C12173 | 485+ | 100 | 6.0 | 2.0MCD | ||||||||
 |
¡@ |  |
